DuraWRX ASP4310-6600711 DEF Header | 11 in | 40 Micron | Digital CANbus

DuraWRX diesel exhaust fluid header assembly, part number ASP4310-6600711, for tanks with an 11 inch header height. Complete header with integrated 40 micron in-tank suction filter, coolant circuit, and digital CANbus level sensor. Covers a wide range of fire apparatus, construction, and off-highway OEM applications.

Key Features:

• Complete DEF header assembly — sensor, suction filter, and coolant circuit in one unit
• 40 micron in-tank suction filter
• Digital CANbus sensor output
• Operating voltage range of 9 to 32 VDC, covering both 12 V and 24 V systems
• Deutsch DT04-4P sealed connector
• 3/8 in SAE J2044 DEF suction and return fittings
• 5/8 in hose bead coolant inlet and outlet

Specifications:

• Part number: ASP4310-6600711
• Brand: DuraWRX
• Component type: DEF header assembly
• DEF header height: 11 in
• In-tank filter: 40 micron
• Sensor type: Digital CANbus
• Operating voltage: 9-32 VDC
• Electrical connection: Deutsch DT04-4P
• Mating connector: Deutsch DT06-4S
• DEF suction fitting: 3/8 in, SAE J2044
• DEF return fitting: 3/8 in, SAE J2044
• Coolant inlet fitting: 5/8 in hose bead
• Coolant outlet fitting: 5/8 in hose bead
• Tank interface: 4.05 in diameter bore seal
• Overall length: 11.434 in (290.42 mm)
• Flange to connector height: 1.895 in (48.13 mm)
• Body diameter: 4.000 in (101.6 mm)
• Weight: 6 lb

Wiring:

• Pin 1, green: CAN low
• Pin 2, yellow: CAN high
• Pin 3, black: ground
• Pin 4, red: power

Compatibility / Fitment:

Covers applications from Cummins, Ditch Witch, Doosan Bobcat, Dynapac, E-ONE, Ferrara Fire Apparatus, Global Environmental Products, Hitachi, Liugong Construction Machinery, Oshkosh, Pierce, Powertraxx Vehicles, SANY, Schachtbau Nordhausen, Taylor Machine Works, TEMSA, Terex, TICO Manufacturing and TICO Tractors. It also replaces Cummins 10002191 and A068H548, and covers Battle Motors applications.

Hard fitment gate — header height and tank interface:

This header is built for an 11 inch header height with a 4.05 inch diameter bore seal tank interface. DuraWRX builds headers in multiple heights, and they are not interchangeable. Measure your existing header and confirm the tank bore before ordering.

Second gate — sensor output. This header uses a digital CANbus sensor. Confirm your system expects CANbus rather than an analog level signal.

Third gate — fitting sizes. Confirm 3/8 in SAE J2044 DEF fittings and 5/8 in hose bead coolant fittings match your installation.

What is not included: the Deutsch DT06-4S mating connector is not supplied and must be ordered separately.

Common interchanges: 4812011099, 4812274581, 3350459, 3329295, 314A-7, 10002191, A068H548, 500-2872, 46857021, 46679525, 46653362, GS382972, YA00084165, YA00083006, SP161165, D004R766, TR1700-596-01, 501740, 501699, 0001089559, 4023 631, 4023 238, 66901701, 62433-1, 620840

Conclusion:

DuraWRX ASP4310-6600711 is the 11 inch DEF header with a 40 micron in-tank filter and digital CANbus sensor, replacing a wide range of OE headers across fire apparatus, construction and off-highway equipment. Confirm your header height, tank bore diameter, sensor output type and fitting sizes before ordering.
