Freightliner DEF Header | ASPFL-2327 | 13/23 Gallon | Detroit | No Valve | New

DuraWRX diesel exhaust fluid header, part number ASPFL-2327, for Freightliner, Western Star and Thomas Built applications with Detroit Diesel engines and 13 or 23 gallon DEF tanks. Replaces the Freightliner analog no-valve header. SAE J2587 flange interface, 20 inch height, with 70 micron mesh suction filter, helical heater and analog level and temperature sensor. Replaces Freightliner 04-33656-000.

Key Features:

• No coolant control valve connection — the Freightliner "no valve" configuration
• Analog level and temperature sensor on an AMP 1-1703818-1 connector
• Helical coolant heater
• 70 micron mesh in-tank suction filter
• Supplied with DuraWRX installation manual

Specifications:

• Part number: ASPFL-2327
• Brand: DuraWRX
• Component type: DEF header assembly with helical heater
• Tank interface: SAE J2587 flange, 4.92 in (125 mm)
• Tank capacity: 13 or 23 gallon
• DEF header height: 20 in
• In-tank filter: 70 micron mesh
• Sensor type: Analog, level and temperature
• Electrical connection: AMP 1-1703818-1
• DEF suction fitting: 5/16 in, SAE J2044
• DEF return fitting: 3/8 in, SAE J2044
• Coolant inlet and outlet fittings: VDA NW08 nipple
• Overall length: 20.08 in (510 mm)
• Flange to connector height: 1.83 in (46.5 mm)
• Flange thickness: 0.79 in (20 mm)
• Harness length: 9.84 in (250 mm)
• Freightliner reference: 04-33656-000
• Weight: 6 lb

Wiring:

• Pin 1: level signal
• Pin 2: level ground
• Pin 3: temperature signal
• Pin 4: temperature ground

Compatibility / Fitment:

Fits Freightliner, Western Star and Thomas Built applications with Detroit Diesel DD13 and DD15 engines and a 13 or 23 gallon DEF tank.

Four hard fitment gates apply:

Tank interface. SAE J2587 flange. Will not fit hose bead, six-bolt or bore-seal tanks.

Coolant control valve. This is the no-valve header. If your vehicle's harness has a coolant control valve connector at the header, you need the CCV version, which is a different header. Match your Freightliner part number before ordering.

Engine platform. Detroit Diesel. Cummins-engine trucks use a different header.

Fitting sizes. This header uses a 5/16 inch suction and 3/8 inch return, with VDA NW08 coolant nipples. The CCV version uses 1/4 inch suction and NG12 coolant ports. Measure before ordering.

Common interchanges: 04-33656-000

Conclusion:

DuraWRX ASPFL-2327 is the SAE J2587 flange no-valve DEF header for Freightliner, Western Star and Thomas Built applications with Detroit DD13 and DD15 engines and 13 or 23 gallon DEF tanks, replacing Freightliner 04-33656-000. Match your Freightliner part number before ordering — the coolant control valve version is a separate header with different fittings.
