Cummins ISX15 Cylinder Kit | 152mm APR Liner | EPA10 CM2250 | Replaces 2881758 + 4376391 | FP Diesel

FP Diesel complete cylinder kit for one cylinder of a Cummins ISX15 EPA10 engine with the CM2250 control module. Includes a piston kit and a 152 mm OD APR liner kit, 17.0:1 compression. Replaces Cummins piston kit 2881758 and liner kit 4376391.

Kit Contents:

All components are new aftermarket parts. Cummins part numbers are listed for reference to identify the OE component each item replaces.

• 1 — Piston kit with pin, retainers and rings, replaces Cummins 2881758 (piston 3688099)
• 1 — Cylinder liner, 152 mm OD APR, replaces Cummins 4373362
• 1 — Anti-polishing ring, replaces Cummins 3689871
• 1 — Liner shim, 0.032 in, replaces Cummins 5298565
• 1 — Liner seal O-ring, blue, replaces Cummins 3685234

Key Features:

• Complete power cylinder for one cylinder — piston kit and liner kit together
• Piston kit includes pin, retainers and rings
• 152 mm OD APR liner with removable anti-polishing ring
• 17.0:1 compression ratio

Specifications:

• Brand: FP Diesel
• Condition: New Aftermarket
• Component type: Cylinder kit, one cylinder
• Liner: 152 mm OD, APR (anti-polishing ring)
• Compression ratio: 17.0:1
• Engine: Cummins ISX15, CM2250, EPA10
• CPL: 3348, 3349, 3376, 3490, 3491, 3687, 3688
• Replaces Cummins: piston kit 2881758, liner kit 4376391
• Quantity per engine: 6
• Weight: 30.2 lb

Compatibility / Fitment:

Fits Cummins ISX15 EPA10 engines with the CM2250 control module and 152 mm APR liners, in the CPLs listed above.

Two hard fitment gates apply:

CPL and piston. This kit uses piston 3688099 for the CPLs above. Other ISX15 EPA10 CPLs (3350-3939, 4584, 4585) use a different piston and kit. Confirm your CPL from the engine dataplate.

152 mm, not 150 mm. Check the liner seal O-ring color on your existing liners: blue is 152 mm (this kit); pink is 150 mm.

Installation: measure liner protrusion with the supplied 0.032 in shim installed, and install the anti-polishing ring after the liner is seated. Install new blue liner seal O-rings lubricated with clean engine oil.

Quantity: one kit per cylinder — six for a full engine.

Conclusion:

FP Diesel’s LK80993362 is the complete 152 mm APR cylinder kit for Cummins ISX15 EPA10 CM2250 engines in CPLs 3348-3688, replacing Cummins piston kit 2881758 and liner kit 4376391. Match your CPL and check for blue liner O-rings before ordering.
