BorgWarner 171702 S400 (S475) Turbo | Detroit Series 60 12.7L 500-550 HP | Replaces 23518597 / 23518588 | New

Genuine new BorgWarner S400 (S400S062 / S475) turbocharger, part number 171702, for Detroit Diesel Series 60 12.7L engines rated 500-550 hp, 2000-2008. Non-wastegated, with a 1.32 A/R twin-scroll turbine housing. Replaces Detroit 23518597, 23518588 and 23523197, Navistar 2585838C91, and Garrett TMF5502 466713-0005.

Key Features:

• Genuine new BorgWarner S400 turbocharger
• Twin hydrodynamic journal bearings; extended-tip compressor wheel
• Twin-scroll 1.32 A/R turbine housing
• Adjustable compressor and turbine housing orientation; compressor cover recirculation grooves

Specifications:

• Part number: 171702
• Brand: BorgWarner
• Turbocharger model: S400S062 / S400SX4 (S475)
• Condition: New
• Component type: Complete turbocharger assembly, non-wastegated
• Compressor wheel: 74.56 mm inducer, 100.17 mm OD
• Turbine housing: 1.32 A/R, twin scroll
• Bearing housing: Oil-cooled
• Engine: Detroit Diesel Series 60, 12.7 L, 500-550 hp (2,100 rpm)
• Model years: 2000-2008
• Detroit reference numbers: 23518597, 23518588, 23523197 (and E / R forms)
• Navistar reference: 2585838C91
• Garrett reference numbers: 466713-0005, 466713-5005S, 466713-9005S, 466713-0006
• CHRA: BorgWarner 171703
• Service kits: 176391 (standard), 1400-711-0003 (360° thrust bearing)
• Gasket kit: BorgWarner 318417
• Weight: 48.6 lb

Compatibility / Fitment:

Fits Detroit Diesel Series 60 12.7L engines rated 500-550 hp, 2000-2008, in Detroit and International / Navistar trucks and generator sets.

Hard fitment gate — 500-550 hp rating:

171702 is for the 500-550 hp 12.7L. It can replace the 470 hp version (BorgWarner 171701), but the 171701 can’t replace this one. Other 12.7L ratings and EGR engines use different turbochargers — confirm your Detroit number and rating before ordering.

Installation: use new gaskets (BorgWarner kit 318417), set the compressor and turbine housing orientation to match your installation before tightening, and prime the turbo with clean oil before start-up.

Upgrade option: BorgWarner 1496-988-0029, with a 76 mm forged milled compressor wheel and 360° thrust bearing.

Common interchanges: 23518597, 23518588, 23523197, 2585838C91, 466713-0005

Conclusion:

BorgWarner 171702 is the genuine new S400 turbo for 500-550 hp Detroit Series 60 12.7L engines, replacing Detroit 23518597 and Garrett 466713-0005. It also replaces the 470 hp 171701, but not the reverse.
