Racor 500MA10 Marine Fuel Filter Water Separator | 10 Micron | Turbine Series | 60 GPH

Racor 500MA Turbine Series marine fuel filter and water separator assembly, part number 500MA10, supplied with a 10 micron Aquabloc element installed. Complete assembly with a clear engineering plastic collection bowl and stainless steel shield. Rated 60 GPH. For diesel fuel only. Racor is a Parker brand.

Key Features

• Complete filter assembly with a 10 micron Aquabloc element installed
• Three-stage filtration — centrifugal separation, coalescing, then filtration
• 98% efficiency at 10 micron
• Aquabloc media repels water rather than absorbing it, extending element life
• Clear collection bowl with stainless steel shield for visual water checks
• Self-venting water drain
• 3/4-16 UNF-2B SAE female ports
• Optional in-bowl water probe available

Specifications

• Part number: 500MA10
• Series: Racor 500 Turbine Series, MA
• Component type: Fuel filter / water separator assembly
• Micron rating: 10 micron, 98% efficiency
• Maximum flow: 60 GPH (227 LPH)
• Maximum pressure: 25 psi
• Bowl: Clear engineering plastic with stainless steel shield
• Ports: 3/4-16 UNF-2B SAE female
• Replacement element: 2010 series
• Fuel type: Diesel and biodiesel only
• Weight: approximately 4 lb
• Condition: New

Compatibility & Fitment

• Marine diesel and biodiesel applications
• Install on the vacuum side of the fuel transfer pump for best efficiency

Coast Guard gate — this assembly has a clear plastic bowl. Coast Guard inspected vessels must use the Racor MAM series with a solid metal bowl. If your vessel is inspected, or carries passengers for hire, confirm your requirements before ordering.

Fuel type gate — this filter is for diesel and biodiesel only. Do not use it in gasoline applications.

Micron selection — the 500MA assembly is offered in 2, 10 and 30 micron versions using the same housing: 500MA2, 500MA10 and 500MA30. 10 micron suits primary or secondary filtration. Choose the rating your engine manufacturer specifies.

Service note — the replacement element is the 2010 series in the matching micron rating. Keep a spare aboard, since a plugged element is the most common cause of a fuel-starvation shutdown.

Conclusion

This is the Racor 500MA Turbine Series marine fuel filter and water separator with a 10 micron element installed, rated 60 GPH for diesel and biodiesel. Confirm your vessel does not require a metal bowl before ordering, and keep a spare 2010 series element aboard.
