Baldwin 20004 Transmission Filter | Allison 1000 2000 2400 | In-Pan, Shallow Pan

Baldwin 20004 in-pan automatic transmission filter for Allison 1000, 2000 and 2400 series LCT transmissions, shallow-pan configuration. Replaces Allison and GM 29537965. Supplied as the filter only — the pan gasket is not included. Baldwin's 20016 is the same filter supplied with a pan gasket.

Key Features

• In-pan (sump) filter for Allison 1000, 2000 and 2400 series LCT transmissions
• Shallow-pan configuration
• Direct replacement for Allison and GM 29537965
• Covers both light-duty GM pickups and a wide medium-duty Allison population
• Baldwin is a Parker brand

Specifications

• Part number: 20004
• Filter type: In-pan automatic transmission filter
• Pan configuration: Shallow
• Transmission: Allison 1000, 2000 and 2400 series LCT
• Length: 9-7/16 in (239.7 mm)
• Width: 6-13/32 in (162.7 mm)
• Height: 4-21/32 in (118.3 mm)
• Pan gasket: not included — see 20016
• Sold as: each

Compatibility & Fitment

• Transmission: Allison 1000, 2000 and 2400 series LCT, shallow pan
• Chevrolet Silverado and GMC Sierra, 2001–2011
• Chevrolet Suburban and GMC Yukon, 2001–2006
• Chevrolet Avalanche, 2002–2006
• Chevrolet Tahoe, 2001 and 2003
• Hummer H1, 2006
• Also fitted across a wide range of medium-duty trucks and buses with Allison LCT transmissions, including GM Kodiak and GMC TopKick, Freightliner M2 and Business Class, Kenworth, Peterbilt, International, Hino, Isuzu and Blue Bird chassis

Fitment gate — this filter is selected by transmission, not by vehicle. Confirm your transmission is an Allison 1000, 2000 or 2400 series LCT with a shallow pan before ordering. Deep-pan applications take a different filter.

Second fitment gate — the pan gasket is not included. Dropping the pan destroys the existing gasket, so order a gasket with this filter or order Baldwin 20016, which is the same filter supplied with one.

Cross-References

• Allison / GM: 29537965, 29537514
• GM: 5745920
• Fleetguard: TF15085
• Hastings: TF183
• Purolator: P1307
• Luber-finer: T951

Conclusion

The Baldwin 20004 is the in-pan transmission filter for shallow-pan Allison 1000, 2000 and 2400 series LCT transmissions, replacing Allison 29537965. Confirm your Allison series and pan depth before ordering, and add a pan gasket — or order 20016, which includes one.
