Garrett 704604-5011S GT4702 Turbo | Caterpillar 3406E / C15 Single Turbo | Replaces CAT 196-5951 | New
Garrett 704604-5011S GT4702 Turbo | Caterpillar 3406E / C15 Single Turbo | Replaces CAT 196-5951 | New
SKU: AIR704604-5011S
| Web Price |
In Stock
Estimated Delivery: November 2 to November 5
Free
Shipping on
Select Items
Satisfaction
Guaranteed!
Secure
Checkout
Free Shipping on Select Items
Satisfaction Guaranteed!
Secure Checkout
New genuine Garrett GT4702 wastegated turbocharger, part number 704604-5011S, for Caterpillar 3406E and C15 engines with a single turbocharger. It replaces Caterpillar 196-5951 and the earlier Garrett 704604-5007S, and ships with mounting gaskets. It is not for the C15 ACERT, which uses a two-turbo system.
Specifications:
- Part number: 704604-5011S (also listed as 704604-0011 and 704604-5011)
- Replaces: Caterpillar 196-5951 and earlier 167-9271; Garrett 704604-5007S
- Brand: Garrett
- Turbocharger model: GT4702, wastegated with pneumatic actuator
- Condition: New
- Component type: Turbocharger assembly
- Engines: Caterpillar 3406E and C15, single-turbo
- Included: mounting gaskets
- Core: None
Compatibility / Fitment:
Fits Caterpillar 3406E and C15 engines with a single turbocharger that use Caterpillar turbo 196-5951 or one of the earlier numbers it replaces.
Two hard fitment gates apply:
Single-turbo engines only. The C15 ACERT uses a two-stage series turbo system with different turbochargers, and this turbo does not fit it.
Turbo number. Caterpillar used more than one single turbocharger on the 3406E and C15. Match the Caterpillar or Garrett number on the turbo you are removing to this part or the numbers it replaces before ordering.
Installation: Clear the intake and charge-air system of any debris from the old turbo, pre-fill the bearing housing with clean engine oil before the first start, and do not use liquid sealant on turbo connections.
Other versions available: A BorgWarner turbocharger supplied under the same Caterpillar number, which we also stock.
Also available remanufactured: A remanufactured version of this turbo, sold with a returnable core.
Conclusion:
This new genuine Garrett GT4702 turbo replaces Caterpillar 196-5951 on single-turbo 3406E and C15 engines and ships with mounting gaskets. Match the number on your old turbo before ordering, and note that it does not fit the C15 ACERT.
