BorgWarner 177148 S410G Turbo | 1994-2007 CAT 3406E 475-550 HP | Replaces CAT 124-3035 | New

New genuine BorgWarner 177148 S410G turbocharger for 1994-2007 Caterpillar 3406E truck engines rated 475 to 550 hp, including the single-turbo C15. BorgWarner built it as a direct replacement with no fitment modifications. It replaces CAT 124-3035 and 196-5951. It ships with the wastegate actuator and mounting gaskets. Match the CAT or BorgWarner number on your old turbo before ordering.

Key Features:

• Genuine BorgWarner S410G turbocharger with integral wastegate
• Wastegate actuator installed; mounting gaskets included
• Extended-tip compressor wheel design
• T6 turbine inlet flange

Specifications:

• Part number: BorgWarner 177148
• Brand: BorgWarner
• Condition: New
• Component type: Turbocharger, wastegated
• Turbo model: S410G
• Turbine inlet flange: T6
• Included: Wastegate actuator 170386 (installed), mounting gaskets
• Engine: Caterpillar 3406E (14.6L), single-turbo C15
• Engine ratings: 475-550 hp
• Years: 1994-2007

Compatibility / Fitment:

Fits 1994-2007 Caterpillar 3406E truck engines rated 475 to 550 hp, including 3406E serial prefix 5EK and the single-turbo C15 with serial prefix 6NZ.

Two hard fitment gates apply:

Match the engine rating. BorgWarner built this S410G for 3406E engines rated 475 to 550 hp. 425-hp engines use a different S410G, and 575-600-hp engines use a separate performance S410G. We stock both. Check the CAT or BorgWarner number on your old turbo’s nameplate before ordering.

Single turbo, not ACERT. This turbo is for the single-turbo 3406E and early C15. The later C15 ACERT uses a series (twin) turbo arrangement with different turbochargers.

Installation: Pre-fill the bearing housing with clean engine oil and prime the oil supply line before first start. Fit new oil supply and drain gaskets. Clear any oil or debris from the intake and charge-air system left by the old turbo. Do not use liquid sealant on oil or exhaust connections. Confirm the wastegate actuator linkage moves freely, and follow Caterpillar’s torque specifications.



Also available remanufactured: A remanufactured S410G for these engines, which we also stock.

Common interchanges: CAT 124-3035, 196-5951, 141-8939, 167-9271, 137-4832 · BorgWarner 170354

Conclusion:

A new BorgWarner S410G turbo for 1994-2007 Caterpillar 3406E engines rated 475 to 550 hp, replacing CAT 124-3035. Confirm the engine rating and the number on your old turbo’s nameplate before ordering.
